High-Precision PCB Drilling Machines for Your PCB Manufacturing Needs

Hans PCB 드릴러

High Precision Drilling: Ensures accurate hole placement with minimal deviation, ideal for complex PCB designs.
고속 성능: Capable of drilling thousands of holes per minute, boosting production efficiency.
Durable and Reliable Design: Built with robust materials to withstand continuous operation in demanding manufacturing environments.
Customizable Options: Supports various drill sizes, board thicknesses, and advanced automation for tailored production needs.

Application: for Printed Circuit Board (PCB) Drilling Hole (Hans Brand)

항목	세부 정보
모델:	HANS-F6MH
프로세스 영역:	622*755mm
XY axis moving speed:	80m/min
Z axis moving speed:	35m/min
위치 정확도:	+/-0.004mm
반복 정확도:	+/-0.0025mm
Spindle speed:	20K~200Krpm
XYZ axis measuring system:	scale, min. resolution 0.5um
Tool broken detection:	Capacitive tool break detection
드릴링 범위:	0.1~6.5mm
드릴링 정확도:	+/-0.018 (Hans condition)
머신 크기:	470020001610mm
기계 무게:	12300kg
